Crawler type fully automatic lifting platform
Crawler type fully automatic lifting platform are a mobile scissor lift specially designed for high-altitude operations under complex road conditions in the field. It has a particularly strong ability to adapt to the environment
We're here to help: Easy ways to get the answers you need!
Crawler type fully automatic lifting platform are a mobile scissor lift specially designed for high-altitude operations under complex road conditions in the field. It has a particularly strong ability to adapt to the environment, and can carry out high-altitude operations in the complicated road conditions without power supply. The crawler scissor lift adopts a weighted chassis, and it does not need outriggers when it is working. When the lift is raised, it still can walk. Its crawler wheels increase the contact area with the earth and can work on complicated roads.
Crawler wheels are suitable for complex roads in the field and have strong adaptability to the environment.
Each equipment has an emergency lowering device to increase the security and stability of high-altitude operation.
Q345 manganese steel material, high strength rectangular tube, solid structure, rust prevention treatment, electrostatic spraying.
The equipment can be debugged through the function keys, and the cause can be found out quickly in case of failure.
| Model | LC-12 |
| Maximum working height | 12m |
| Maximum platform height | 10m |
| Safe working load | 320kg |
| Extended Platform Safety Workload | 110kg |
| Work platform size | 2.27×1.12×1.13m |
| Overall dimensions of the machine | 2.42×1.39×2.59m |
| Minimum ground clearance | 0.15m |
| Track width | 300mm |
| Walking motor | 2×4kw/DC48V |
| Lifting motor | DC48V/4.5kw |
| Lifting speed | 9-10m/min |
| Maximum driving speed | 3.5km/h |
| Max Climb Capability | 0.25 |
| Overall weight | 2950kg |
