LICHMACH Loader LC 646G

Performance

Powerful Performance:

At the heart of the LC 646G loader is a robust engine that redefines power and efficiency. The Doyen WP6G175E301 engine boasts a staggering 125 kW of rated power at 2000 rpm, ensuring that no task is too demanding. With a Euro II emission standard, it not only delivers exceptional power but also does so while being environmentally conscious. The 6-cylinder, 105 mm bore, and 130 mm stroke configuration guarantee unparalleled performance, making it the ideal choice for heavy-duty applications.

Built for Tough Challenges:

The LC 646G is built to handle heavy loads with ease. It comes equipped with a rated loading capacity of 4000 kg, allowing you to take on substantial tasks without breaking a sweat. The maximum traction force of 95 KN and a maximum breakout force of 127 KN ensure that even the most stubborn materials are moved effortlessly. With a tipping load of 9860 kg, this loader can handle it all.

Precision in Every Move:

Efficiency and precision are the hallmarks of the LC 646G loader. Its 2.0 m³ bucket capacity ensures that you can handle more material in each scoop, reducing cycle times and boosting productivity. The minimum turning radius of 5929 mm ensures that you can navigate tight spaces with ease, making it versatile for various job sites. Moreover, the maximum dump height of 3200 mm and maximum dump reach of 1260 mm give you the flexibility to load and unload materials efficiently.

Comfort and Convenience:

Operating the LC 646G loader is a breeze, thanks to its user-friendly design. The spacious and ergonomic cabin provides the operator with a comfortable and fatigue-free environment. With a maximum grade ability of 30℃, this loader can tackle uneven terrains effortlessly. The hydraulic system works at a pressure of 16.5 MPa, ensuring smooth and precise control of the boom lifting and total operation time.

Reliable Transmission:

The LC 646G comes with a reliable transmission system, featuring a torque converter (YJ315-X) and a gearbox with 4 forward gears and 2 reverse gears. This ensures smooth and efficient power delivery, allowing you to switch between different tasks seamlessly. With a maximum speed of 38 km/h, you can move swiftly around the job site, further enhancing your productivity.

Safety and Control:

Safety is a top priority with the LC 646G loader. It features air-assist disc brakes on all four wheels for superior service braking and a manual disk brake for parking. This dual-brake system ensures that you have full control over the loader in any situation, guaranteeing the safety of both the operator and the equipment.

Built to Last:

Durability is a key factor in the design of the LC 646G. The main reducing spiral with bevel gear grade 1 reduction and planetary reduction grade 1 ensure the longevity and reliability of the drive axles. With a wheelbase of 2820 mm, a wheel tread of 1450 mm, and a ground clearance of 400 mm, this loader is ready to conquer even the toughest job sites.

Tires That Stand Tall:

The LC 646G comes equipped with 20.5-25 tires, designed to handle rough terrains with ease. The front tire pressure of 0.4 MPa and rear tire pressure of 0.35 MPa ensure optimal traction and stability, even in challenging conditions.

LICHMACH Loader LC 646G is more than just a loader; it's a powerhouse of performance, precision, and reliability. Whether you're in construction, mining, or any industry that demands heavy lifting, this loader is your ultimate partner. Don't settle for less when you can have it all with the LC 646G. Upgrade your equipment fleet and experience the difference today. Order Now
