LICHMACH LC320 Bulldozer

Introduction

A bulldozer is an earthmoving machinery capable of excavating, transporting and discharging rock and soil. It is widely used in open pit mines. For example, it is used to build earth dumps, level vehicle dumps, accumulate scattered mineral rocks, level work flats and construction sites, etc. It is not only used for auxiliary work, but also for main mining work. For example: stripping and mining of sand deposits, traction and boosting of scrapers and rock plows, cooperating with other earthmoving machinery to reduce the height of the stripping step when there is no transportation mining method.

Walking Style

Bulldozers can be divided into two types: crawler type and tire type. The crawler bulldozer has large adhesion and traction, small ground specific pressure (0.04 to 0.13MPa), and strong climbing ability, but its driving speed is low. The tire-type bulldozer has high driving speed, flexible maneuverability, short operation cycle time, and convenient transportation and transfer. However, it has small traction force and is suitable for situations where construction sites and field work need to be frequently changed.

According To Use

It can be divided into two types: general type and special type. The universal type is a model produced according to standards and is widely used in earthworks. Special-purpose bulldozers are used under specific working conditions, including wetland bulldozers and swamp bulldozers that use triangular wide track shoes to reduce ground contact pressure, amphibious bulldozers, underwater bulldozers, cabin bulldozers, unmanned bulldozers, plateau prototypes, and high-altitude bulldozers. Bulldozers operating in wet conditions, etc.

◆ The appearance of the vehicle is based on optimization design
◆ Higher engine power reserves efficiency ,bigger torque output ,lower fuel consumption ,while better reliability
◆ Hydraulic controlled drive,automatically speed regulation and non-stop gear shifting
◆ 3-element,single stage,single phase torque converter for higher efficiency and bigger capacity
◆ The novel hexahedral cad offers excellent visibility, the powerful ventliation and unparalleled dust-free.
◆ The final drive uses triangle Spline and tip lelief, crowned gear drive to enhance the balance and the stability of the load of transmission part
◆ New blade is more durable and capacious
◆ Alarming monitoring system is efficient and reliable
◆ Implement controls are piloted to minimize operating effort

Technical parameters
