Road Roller

Performance Metrics

Each of our models is engineered with precision, incorporating a wide array of technical features to meet different operational requirements. These specifications include dimensions, operating weight, drum width, static linear pressure, vibration frequency, centrifugal force, and engine output. These metrics are crucial for understanding the capabilities and limitations of each model, ensuring that you choose the right equipment for your specific needs.

Static Linear Pressure

Our models offer a range of static linear pressures, starting from 228 N/cm in the GYS08 to a whopping 509 N/cm in the GYS222. This ensures optimal soil and material compaction, making your construction work more durable and long-lasting.

Vibration Frequency

The vibration frequency varies between models, ranging from 28 Hz in the GYS222 to 48 Hz in the GYS08. This allows for more effective material compaction, especially in projects that require varying degrees of soil density.

Centrifugal Force

The centrifugal force starts at 85 KN in the GYS08 and goes up to 390 KN in the GYS222. This wide range provides the necessary force for tasks ranging from light soil compaction to heavy-duty road construction.

Engine Details

The engine is the heart of any machine, and our models come with engines that are optimized for their respective operational needs. For instance, the GYS08 is powered by a XINCHAI 498BG engine with a rated output of 42 KW, making it ideal for less demanding tasks. On the other end of the spectrum, the GYS222 features a WEICHAI WP6G190E301 engine with a rated output of 140 KW, providing the power needed for the most demanding projects. Each engine is designed for optimal fuel efficiency and long-term reliability.

Traveling Speeds

The ability to adjust traveling speeds is crucial for operational efficiency. Our models offer a range of speeds in both forward and reverse directions. For example, the GYS08 has a maximum forward speed of 15.5 km/h, allowing for quick movement between work sites. The GYS222, while more powerful, has a maximum forward speed of 10.3 km/h, optimized for heavy-duty tasks that require more precision.

Dimensional Specifications

The dimensions of each model are carefully designed to offer a balance between operational efficiency and ease of transport. For example, the GYS08 has dimensions of 5180×1830×2700 mm, making it compact enough for easy transport and storage. The GYS222, with dimensions of 6503×2390×3250 mm, is built for large-scale operations where size and power are of the essence.

Comparison of Models

When choosing a model, it's important to consider various factors:

Size and Scale: The GYS08 is ideal for smaller, more compact projects, while the GYS222 is designed for large-scale, heavy-duty operations.

Engine Output: The engine power ranges from 42 KW in the GYS08 to 140 KW in the GYS222, allowing you to choose a model based on the energy needs of your project.

Traveling Speed: While the GYS08 offers higher speed options, making it ideal for tasks requiring quick movement, the GYS222 is optimized for heavy-duty tasks that require more control and precision.

Vibration and Force Metrics

The vibration frequency and centrifugal force are key metrics that significantly impact the effectiveness of material compaction. Higher-end models like the GYS222 offer greater centrifugal force and a lower range of vibration frequencies, making them ideal for heavy-duty applications where maximum compaction is required.

Operational Efficiency

Operational efficiency is at the core of our design philosophy. Features like multiple traveling speeds, adjustable vibration frequencies, and a range of engine outputs allow operators to fine-tune the machine's performance based on the specific requirements of each task. This ensures that you are always operating at peak efficiency, saving both time and resources.

Safety and Compliance

Safety is our top priority. All our models are engineered to meet or exceed industry standards for safety and compliance. Features such as emergency stop buttons, safety belts, and protective cabins are standard across all models. This ensures the well-being of the operator while also minimizing the risk of operational mishaps.

Technical parameters

Model	GYS08
Length×Width×Height(mm)	5180×1830×2700
Operating weight (Kg)	8000
Drum width (mm)	1650
Static linear pressure （N/cm）	228
Vibration frequency (Hz）	48
Centrifugal force（KN）	85
Traveling speed（km/h）
Forward	2.0/4.2/7.5/12.5/15.5
Reverse	2.0/3.5
Diesel engine	XINCHAI 498BG
Rated output(KW)	42

Model	GYS10
Length×Width×Height(mm)	5450×2160×3010
Operating weight (Kg)	10000
Drum width (mm)	1980
Static linear pressure （N/cm）	230
Vibration frequency (Hz）	30
Centrifugal force（KN）	225/105
Traveling speed（km/h）
Forward	2.0/4.2/8.7
Reverse	2.0/4.2
Diesel engine	WEICHAI WP4G110E211
Rated output(KW)	82

Model	GYS14
Length×Width×Height(mm)	6140×2280×3080
Operating weight (Kg)	14000
Drum width (mm)	2130
Static linear pressure （N/cm）	320
Vibration frequency (Hz）	30
Centrifugal force（KN）	305/150
Traveling speed（km/h）
Forward	2.0/4.0/8.7
Reverse	2.0/4.0
Diesel engine	WEICHAI WP4G110E221
Rated output(KW)	82

Model	GYS16
Length×Width×Height(mm)	6170×2320×3050
Operating weight (Kg)	16000
Drum width (mm)	2130
Static linear pressure （N/cm）	380
Vibration frequency (Hz）	30
Centrifugal force（KN）	305/165
Forward	2.9/5.7/11.6
Reverse	2.9/5.7
Diesel engine	WEICHAI WP6G160
Rated output(KW)	118
